Amphenol 350-2700 MHz 4.3-10 DAS Tapper - 48dB

Amphenol 350-2700 MHz 4.3-10 DAS Tapper - 48dB




TTS PRICE: $116.99

STATUS:  IN STOCK



Availability:
Normally Ships Same Day

PRODUCT CODE: HOL-HPT48-B-35027
QUANTITY:

PRODUCT DESCRIPTION


Amphenol's Tappers receive and distribute high power, wireless signals in a fixed proportion to the DAS network. With RF performance optimized for carrier signals in the 350-2700 MHz bands, the HPT48-B-35027 offers fixed-ration split of 3:1. These tappers offer low VSWR (high return loss) at the input port. Tight machining tolerances in the internal air dielectric design allow a narrow flatness tolerance to the tap port. Materials and plating were carefully chosen to achieve minimal PIM for low PIM applications.

These DAS tappers offer excellent signal reliability indoors and out - meeting IP67 specifications.

Features:
  • Low PIM Tested and Verified
  • 500 Watt Average Power Rating
  • Minimal RF Insertion Loss
  • High Environment Reliability; IP67
  • RoHS Compliant

  • Specifications:
  • Output Split Ratio, Nominal (dB Inequality between Outputs): 3:1/4.8dB
  • Outputs Ref. to Input Level, Including Loss (dB):
    • Main/Branch (dB): -1.3/-6.1
    • Branch Flatness: ±0.7
  • Input VSWR Maximum:
    • 700-2500 MHz: 1.3:1
    • 350-2700 MHz: 1.3:1
  • Frequency Bands: 350 - 960 MHz and 1,710 - 2,700 MHz; Uncoupled: 1550-1650 MHz
  • Dissipative Loss: 0.1 dB ,am/ (main line)
  • Power Rating: 500W avg., 3 kW peak
  • Impedance: 50Ω nominal
  • Intermod. (PIM): <-161 dBc (Test with 2x20W tones)
  • Environment: IP67
  • Temperature Range: -35°C to -75°C
  • Connectors (Body/Finish): Brass/Trimetal
  • Housing Finish: Passivated Aluminum
  • Weight, nom: 14 oz (380 g)
  • Mounting: Bracket supplied
