Cable Prep JCS-565 Jacket Stripper for .565 PIII & TX10 Hardline

Home > Categories > Cable Prep & Termination > Jacket Strippers >

Alternative Views:

TTS PRICE: $42.99

STATUS: ON ORDER

Availability:

SHIP ESTIMATE 5-7 DAYS

PRODUCT CODE: CPR-JCS-565

QUANTITY:

PRODUCT DESCRIPTION

Cable Prep JCS-565 Jacket Stripping Tool - .565 PIII & TX10 Hardline, Orange Guide Sleeve

The Cable Prep JCS-565 cleanly strips the jacket on .565 PIII & TX10 trunk and distribution cable. The dual-edged tool-steel blade bites into and lifts the jacket without damaging the soft outer conductor, and the plastic guide sleeve keeps every metal surface off the aluminum. It threads onto the matching Cable Prep SCT tool for jacket strip, strip, bevel and core in one operation.

Features:

Dual-edged, heat-treated tool-steel blade - easy to replace after a long life

Knurled, anodized and sealed tool body for a firm grip

Orange plastic guide sleeve - color matched to the Cable Prep SCT tool

Guide sleeve keeps all metal surfaces away from the soft aluminum outer conductor

Threads onto the matching SCT stripping/coring tool

Specifications:

Type: Hardline Cable Jacket Stripping Tool

Cable Size/Type: .565 PIII & TX10

Guide Sleeve Color: Orange

Blade: Dual-edged heat-treated tool steel

Body: Knurled, anodized and sealed

Weight: 0.44 lb (0.2 kg)

Model: JCS-565

Available Sizes (JCS Jacket Strippers):

Part #	Cable Prep #	Cable	Color Code	Weight	Blade Kit
CPR-JCS-412	JCS-412	.412 T10 & PIII	Light Blue	0.46 lb (0.21 kg)	JSB-3011
CPR-JCS-500	JCS-500	.500 T10 & PIII	Yellow	0.44 lb (0.2 kg)	JSB-3011
CPR-JCS-625	JCS-625	.625 T10 & PIII	Green	0.42 lb (0.19 kg)	JSB-3011
CPR-JCS-750	JCS-750	.750 T10 & PIII	Red	0.4 lb (0.18 kg)	JSB-3011
CPR-JCS-875	JCS-875	.875 T10 & PIII	Grey	0.34 lb (0.16 kg)	JSB-3011
CPR-JCS-1000	JCS-1000	1.000 T10 & PIII	Black	0.34 lb (0.16 kg)	JSB-3025
CPR-JCS-565	JCS-565 (this item)	.565 TX10 & PIII	Orange	0.44 lb (0.2 kg)	JSB-3011
CPR-JCS-700	JCS-700	.700 TX10 & PIII	Maroon	0.42 lb (0.19 kg)	JSB-3011
CPR-JCS-840	JCS-840	.840 TX10 & PIII	Light Grey	0.38 lb (0.17 kg)	JSB-3011

Replacement Parts:

Part #	Cable Prep #	Description
-	JSB-3011	JCS replacement blade kit for JCS-565

Fits These Tools:

Part #	Cable Prep #	Description
CPR-SCT-565	SCT-565	SCT-565 strip & core tool - .565 PIII & TX10, plastic, standard handle
CPR-SCT-565-ALU	SCT-565-ALU	SCT-565-ALU strip & core tool - .565 PIII & TX10, aluminum, standard handle
CPR-RSCT-565	RSCT-565	RSCT-565 strip & core tool - .565 PIII & TX10, plastic, ratchet T-handle
CPR-RSCT-565-ALU	RSCT-565-ALU	RSCT-565-ALU strip & core tool - .565 PIII & TX10, aluminum, ratchet T-handle

JCS Jacket Stripping Tools Brochure
