Klein Tools Parallel Jaw Grip 4500 Series - 0.18 to 0.60in

Klein Tools Parallel Jaw Grip 4500 Series - 0.18 to 0.60in




Alternative Views:
TTS PRICE: $205.67


STATUS:  IN STOCK



Availability:
Normally Ships Same Day

PRODUCT CODE: KLN-KT45005C
QUANTITY:

PRODUCT DESCRIPTION


This versatile grip from Klein Tools (KT45005C) holds a broader range of ACSR cable sizes, reducing the number of grips needed. Klein Parallel Jaw Grips are lightweight and compact. The round jaw holds 0.18 to 0.60-Inch diameter cable with a maximum safe load of 5000 lbs. Features a spring that closes the grip on the cable to maintain the initial position.

Features:
  • Versatile grip holds a wider range of Guy Strand, EHS and coated cable sizes reducing the number of grips needed
  • Round jaw holds 0.18 to 0.60-Inch (4.57 to 15.24 mm) diameter cable range
  • Spring closes grip on cable to hold the initial position
  • Sawtooth jaw profile ensures optimal grip strength on guy strand and EHS cables
  • Spring‐loaded for easy one‐handed operation
  • Large opening in the handle accommodates a wide variety of hooks on hoists, winches and tackle blocks
  • Max Safe Load of 5000-Pound (2268 kg)
  • Alternating sawtooth jaw geometry provides greater grip strength
  • Longer jaw increases surface area contact with cable eliminating cable damage
  • Designed to work with galvanized guy wire
  • Spring helps maintain cable position in grip jaw

    • Specifications:
  • Type: Parallel Jaw Grip
  • Application: Cable Pulling
  • Special Features: Sawtooth Jaw Profile Ensures Optimal Grip Strength on the Cable/Wire
  • Overall Length: 10.9'' (27.7 cm)
  • Overall Height: 4.6'' (11.7 cm)
  • Overall Width: 1.9'' (4.8 cm)
  • Material: Steel
  • Cable Type: Guy Strand, EHS, Coated
  • Cable Diameter: 0.18'' to 0.6'' (4.57 to 15.2 mm)
  • Hot Latch: N
  • Swing Latch: No
  • Spring: Y
  • Locking Handle: No
  • Jaw Type: Round - Serrated
  • Jaw Length: 4'' (10.2 cm)
  • Maximum Safe Load: 5000 lb (2268 kg)
  • Weight: 3.8 lb (1.7 kg)

    • Clean your wire pulling grips with Klein's Grip-Cleaning Brush Set here: KLN-25450.
