Ripley 34735 WS 57A Jacket, Insulation & Semi-Con End Stripper

Home > Categories > Utility & MV Cable Prep > Cable End Strippers >

UtilityTool by Ripley Tools WS 57A Adjustable Jacket, Insulation & Semi-Con End Stripper - 45-115kV, 2.0-4.25in

Alternative Views:

TTS PRICE: $2,209.09

STATUS: ON ORDER

Availability:

SHIP ESTIMATE 6-8 DAYS

PRODUCT CODE: RIP-34735

QUANTITY:

PRODUCT DESCRIPTION

Ripley UtilityTool WS 57A Adjustable Jacket, Insulation & Semi-Con End Stripper - 45-115 kV

The WS 57A strips the outer jacket and insulation from 45 to 115 kV cable 2.0" to 4.25" (50.8 to 108 mm) in diameter, and adds an adjustable semi-con shaving blade system so one tool prepares the whole cable end.

A quick-slide adjustment mechanism fits the cable diameter, and the adjustable blade depth and angle control the width of the end strip.

Features:

Strips jacket and insulation on 45-115 kV cable, 2.0-4.25in (50.8-108 mm)

Adjustable semi-con shaving blade system

Quick-slide adjustment for cable diameter

Adjustable blade depth and angle control the end strip width

Specifications:

Model: Ripley UtilityTool WS 57A (Ripley Part # 34735)

Cable OD: 2.0-4.25in (50.8-108 mm)

Voltage: 45 kV - 115 kV

Insulation: XLPE, EPR, PE

Shaves Semi-Con: Yes

Material: Aluminum

Length: 24in (610 mm)

Weight: 7 lb (3.18 kg)

Available Models:

Part #	Model	Ripley #	Shaves Semi-Con	Replacement Blades
UTIL-34320	WS 57	34320	No	34327
RIP-34735	WS 57A (this item)	34735	Yes	34327 (jacket), 21715 (semi-con)

Replacement Parts:

Part #	Ripley #	Description
-	34327	CB 144 end strip blade
-	21715	CB 40X semi-con blade

WS 57 Instruction Sheet
