U-Teck Fiber Optic Splicing Workstation

U-Teck Fiber Optic Splicing Workstation

Alternative Views:


TTS PRICE: $376.99

STATUS: ON ORDER


Availability:
SHIP ESTIMATE 9-11 DAYS

PRODUCT CODE: UTECK-55706
QUANTITY:

PRODUCT DESCRIPTION


Take a real workbench to the splice point. The U-Teck Fiber Optic Splicing Workstation gives fiber techs a stable, generous work surface wherever splicing happens - as a freestanding bench, in narrow manhole setups, inside a tent, at the central office, or up at the strand. The molded table measures approximately 35-1/2 in. x 22-1/2 in. with a recessed 22 in. x 18 in. work area that keeps sleeves, parts and small tools from rolling off, and built-in slots and holes hold your tools right where you reach for them.

The heavy-duty steel legs lock firmly to the table at a comfortable 31-1/2 in. working height, and the whole station folds flat for transport. Four accessory slots accept U-Teck's stand-offs, aerial strand cables and other add-ons, so one table adapts to ground, wall-hang and aerial work.

This is the standard configuration: workstation table, adjustable-height floor stand and the Cable Management Bracket, which fits securely on either side of the bench and keeps jacketed strands put and separated until you need them. Set up with table, stand and bracket it weighs just 17.63 lb.

Features:
  • Portable fiber splicing workbench with large molded work surface
  • Recessed work area keeps splice sleeves and small parts contained
  • Built-in slots and holes hold tools, parts and splicing equipment
  • Heavy-duty steel legs lock to the table; folds flat for transport
  • 4 accessory slots accept stand-offs, aerial strand cables and add-ons
  • Works freestanding, wall-hung over terminals, or at the aerial strand
  • Cable Management Bracket included - keeps jacketed strands separated

  • Includes:
  • Workstation table - 35-1/2 in. x 22-1/2 in. molded work surface
  • Floor stand, adjustable height (32 in. / 41 in.) - UTECK-55705-STAND
  • Cable management bracket - UTECK-55730

  • Specifications:
  • Model: 55706
  • Work surface: approx. 35-1/2 in. x 22-1/2 in.
  • Recessed work area: 22 in. x 18 in.
  • Working height: 31-1/2 in.
  • Weight capacity: 100 lb
  • Weight w/ table, floor stand and bracket: 17.63 lb

  • U-Teck Splicing Workstation System:
    Part # U-TECK # Description
    UTECK-55706 55706 Workstation - floor stand + cable management bracket (this item)
    UTECK-55701 55701 Workstation - floor stand, bracket + stand-offs
    UTECK-55700 55700 Workstation - floor stand, 1/4-20 splicer mount
    UTECK-55700-B 55700-B Workstation - floor stand, M6 splicer mount
    UTECK-55700-1 55700-1 Complete kit - workstation with every accessory
    UTECK-55700-3 55700-3 Aerial table top only - strand clamps, 1/4-20 splicer mount
    UTECK-55705-STAND 55705-Stand Floor stand only - adjustable height (32 in. / 41 in.)
    UTECK-55730 55730 Cable management bracket
    UTECK-55711 55711 Stand-offs - hang the table from a terminal or wall
    UTECK-55715 55715 Aerial strand cables - hang the table from the strand
    UTECK-55615 55615 LED dual power light with magnifying glass
    UTECK-55720 55720 Tablet holder
    UTECK-55725 55725 Splice tray holder
    UTECK-55712 55712 Fiber splice case stand
    UTECK-55755 55755 Fiber-Grip splicing clamp
    UTECK-55801 55801 Cleaver mount
    UTECK-55740 55740 Wheel kit
    UTECK-55742 55742 Leveling kit
    UTECK-55745 55745 Splicer seat tether
    UTECK-55710 55710 Black poly-mesh 3-pocket pouch

    Fiber Optic Splicing Workstation Data Sheet
