Featuring the EXO Crimp Frame with the EXO-EX and the EZ-RJ45 interchangeable die sets, the EXO CST Kit has everything you need to cut, strip, and terminate Cat5e, Cat6, and Cat6A cables. The EZ-RJ45 Die works with standard EZ-RJ45 connectors to terminate Cat5e cables while the EXO-EX Die works with the ezEX™44 and ezEX™48 connectors to terminate larger Cat6 and Cat6A cables.
1 - EXO Crimp Frame + EXO-EX Die
1 - EZ-RJ45 Die
1 - Cyclops 2 Cable Jacket Stripper
1 - Electrician’s Scissors
1 - 5” Side Cutting Pliers
50pc - EZ-RJ45 CAT5e
50pc - ezEX44, ezEX-RJ44
25pc - ezEX48, ezEX-RJ45
Platinum Tools EXO Crimp Frame w/ EXO-EX Die:
This EXO Crimp Frame comes equipped with Platinum Tools EXO-EX die which is designed specifically for the exEZ-RJ45 connector. If you are not familiar with the ezEX-RJ45 connectors, they were engineered specifically for terminating larger diameter twisted-pair cables with conductor sizes up to .048in. The exEZ-RJ45 allows for the larger wire by cleverly staggering each conductor. As with all EZ connectors, the wiring can be quickly verified by the wires protruding prior to crimping. It is important to note the exEZ-RJ45 connectors can only be crimped with this EXO crimper and EXO-EX Die.
Insulation Diameter (Conductor) size range: 0.039” to 0.048” (depending on connector)
Max Outer Diameter: .290” (7.36mm)
Length: 8-1/2” (216 mm)
Weight: Frame and Die 15.08 oz. (427.4 g)
Platinum Tools EZ-RJ45 Die for EXO Crimp Frame:
The patented EZ-RJ45 Die from Platinum Tools is used with the EXO Crimp Frame to terminate EZ-RJ45 connectors. The EZ-RJ45 Die is interchangeable and reversible when used with EXO Crimp Frame. Designed for the original pass through EZ-RJ45 connectors which are a standard in the industry.
Single cycle crimp and flush trim
Reversible for ambidextrous operation
Connectors lock into tool for correct positioning during crimp
Compatible with EZ-RJ45 connectors
Cyclops 2 Cable Jacket Stripper:
The Cyclops 2 takes the guesswork out of removing the cable jackets from many types of twisted pair, multicore and fiber optic cables. The tool self adjusts to automatically cut PVC, plenum and others without damaging the braids, foils or conductors. One piece design, ready to use right out of the package. Typical applications are in data, voice, video, audio, security and others.
Ring pull for middle finger
An original favorite, this smooth cutting action, scissor-run design is excellent for cutting Kevlar®, foil and wire. Cuts solid wire up to 16 AWG and stranded up to 12 AWG. Strips 19 and 23 AWG.
Full serrated bottom blade for non-slip cutting
Scraper and file on backside of blades
Inside blade is chrome plated for rust protection
Easily re-sharpens & holds cutting edge
Stripping notches for 19 & 23 AWG wire
Screw permits easy adjustment
5” Side Cutting Pliers:
The 5" Side Cutting Pliers are perfectly suited for field or production line work. Use for cutting copper wire or trimming leads with the full flush cutting blades. The tool is manufactured from high carbon tool steel, precision ground and hardened for long life. Molded comfort grip handle. Rust resistance black oxide finish.
Cuts copper wire and soft metals up to 16 AWG (.05)
21° full flush cut
Comfort grip vinyl handle
