Ripley 37730 WS-MSES #2 150 mil Tap Wire Mid-Span Stripper

Home > Categories > Utility & MV Cable Prep > Cable End Strippers >

UtilityTool by Ripley Tools WS-MSES #2 150 mil Tap and Riser Wire Mid-Span Stripper - #2 AWG, 150 mil Covering

TTS PRICE: $277.99

STATUS: ON ORDER

Availability:

SHIP ESTIMATE 9-11 DAYS

PRODUCT CODE: UTIL-37730

QUANTITY:

PRODUCT DESCRIPTION

The UtilityTool WS-MSES strips the mid-span and ends of primary voltage tap and riser wire.
It removes a section of the polyethylene covering at mid-span so the wire clamps easily to lightning arrestors.

Opens and closes in a second.
A spring-loaded locking bolt opens the tool halves to drop it onto the cable, and the pull ring at the end of the bolt clips to a belt or pouch. This model is sized for #2 AWG wire with 150 mils covering - see the chart for other sizes.

Features:

Strips the mid-span and ends of primary tap and riser wire

Removes the polyethylene covering for clamping to lightning arrestors

Spring-loaded locking bolt opens the tool body for quick positioning on the cable

Pull ring attaches to tool belts and pouches

Sized for #2 AWG with 150 mils covering

Specifications:

Model: Ripley UtilityTool WS-MSES #2 150 mil (Ripley Part # 37730)

Cable Size: #2 AWG

Insulation Thickness: 150 mils

Cable Type: Tap and riser wire

Length: 4.25in (108 mm)

Weight: 15 oz (426 g)

Available Sizes:

Part #	Model	Ripley #	Cable Size	Insulation	Replacement Blade
UTIL-37380	WS-MSES #4 110 mil	37380	#4	110 mils	37111
UTIL-37384	WS-MSES #6 Solid 110 mil	37384	#6 Solid	110 mils	37111
UTIL-37388	WS-MSES #2 110 mil	37388	#2	110 mils	37111
UTIL-38060	WS-MSES #4 Solid 110 mil	38060	#4 Solid	110 mils	37111
UTIL-37715	WS-MSES #4 150 mil	37715	#4	150 mils	37803
UTIL-37730	WS-MSES #2 150 mil (this item)	37730	#2	150 mils	37803
UTIL-37800	WS-MSES #6 150 mil	37800	#6	150 mils	37803
