LC Simplex OM4 UPC Splice-On Connector, Low-Loss Fiber Optic 900µm

LC Simplex OM4 UPC Splice-On Connector, Low-Loss Fiber Optic 900µm


Alternative Views:
TTS PRICE: $8.63


STATUS:  IN STOCK

Free Shipping

Availability:
Normally Ships Same Day

PRODUCT CODE: AI-LCS-OM4-UPC-09-SA
QUANTITY:

PRODUCT DESCRIPTION


The UCL Swift LC Multimode OM4 UPC Splice-On Connector (AI-LCS-OM4-UPC-09-SA) is engineered for high-density optical transmission applications such as FTTH, LAN, POL, CATV, and data centers. Designed for 900 µm fiber, this connector combines factory-polished ferrule end faces with fusion splice technology, ensuring low insertion loss, high return loss, and reliable long-term performance. Built for fast, repeatable field installation, it is ideal for technicians requiring consistent results in multimode OM4 networks.

Features
  • Factory-installed fiber stubs using premium-grade OM4 fiber
  • Factory-polished and inspected ferrule end faces for consistent optical performance
  • Enhanced tensile strength exceeding 60 N
  • FOCIS-compliant LC connector interface
  • Verified to TIA-568-C.3 performance standards
  • Reliable, repeatable field termination process
  • Available with U.S.-made connectors
  • Backed by Swift’s 25-year warranty
Specifications:
  • Model: AI-LCS-OM4-UPC-09-SA
  • Connector type: LC
  • Fiber type: Multimode OM4
  • Polish: UPC (Ultra Physical Contact)
  • Cable compatibility: 900 µm
  • Tensile strength: > 60 N
  • Return loss (UPC): > 30 dB
  • Insertion loss: Average < 0.15 dB (Max < 0.30 dB)
  • Compliance: TIA-568-C.3, IEC61754, KS C6974, JIS C5973
Applications
  • FTTH (Fiber-to-the-Home) networks
  • LAN and enterprise data networks
  • Passive Optical LAN (POL) systems
  • CATV networks
  • Data center interconnects
